升华（昇华）电阻产品
符合ROHS法規限值低阻抗值(可低至0.5m ohm) 精密容差(標準±5%,±1%，也可提供±0.5%) 耐高溫使用環境(可達到+275℃) 低温度係數(可低至15ppm/℃以下) 低感值(0.5-5nH) 熱電耦效應 EMF (可低至1uV/℃) 耐高電流使用(大於125A) 高功率密度多種外觀尺寸(2725/2512/2010/1206/0805 )
封装：2725	( 1 ) Size 2725 ( 2 ) Power Rating R: 3W E : 4W ( 3 ) Resistance Value 0.0005~0.1 Ω ( 4 ) Tolerance D= ± 0.5 %；F= ± 1%；G= ± 2%；J= ± 5% ( 5 ) Packaging Type T: 1000PCS / Taping Reel 2725 Size Operating Temperature Range -65℃~275℃ Temperature Coefficient ±50 ppm/℃~±100ppm/℃
封装：2512	( 1 ) Size 2512 ( 2 ) Power Rating S: 2 W T: 1 W A: 1.5 W R: 3 W U : 0.5W ( 3 ) Resistance Value 0.001~0.2 Ω ( 4 ) Tolerance D= ±0.5 %；F= ±1%；G= ±2%；J= ±5% ( 5 ) Packaging Type T: 2000PCS / Taping Reel 2512 Operating Temperature Range -65℃~275℃ Temperature Coefficient ±50 ppm/℃~±100ppm/℃
封装：2010	( 1 ) Size 2010 ( 2 ) Power Rating S: 2 W T: 1 W A: 1.5 W U : 0.5W ( 3 ) Resistance Value 0.001~0.1 Ω ( 4 ) Tolerance D= ±0.5 %；F= ±1%；G= ±2%；J= ±5% ( 5 ) Packaging Type T: 2000PCS / Taping Reel 2010 Size Operating Temperature Range -65℃~275℃ Temperature Coefficient ±50 ppm/℃~±100ppm/℃
封装：1206	( 1 ) Size 1206 ( 2 ) Power Rating T: 1 W U : 0.5W ( 3 ) Resistance Value 0.001~0.1 Ω ( 4 ) Tolerance D= ±0.5 %；F= ±1%；G= ±2%；J= ±5% ( 5 ) Packaging Type T: 4000PCS / Taping Reel 1206 Size Operating Temperature Range -65℃~275℃ Temperature Coefficient ±50 ppm/℃~±100ppm/℃
封装：0805	( 1 ) Size 0805 ( 2 ) Power Rating U : 0.5W V : 0.25W ( 3 ) Resistance Value 0.002~0.05 Ω ( 4 ) Tolerance D= ±0.5 %；F= ±1%；G= ±2%；J= ±5% ( 5 ) Packaging Type T: 5000PCS / Taping Reel 0805 Size Operating Temperature Range -65℃~275℃ Temperature Coefficient ±50 ppm/℃~±100ppm/℃
